XCMG is a well-known manufacturer of construction machinery, and its product quality has always been highly praised. The QY8D-I crane is made of high-quality materials and with advanced manufacturing techniques, featuring a long service life and excellent durability.
A set of retired machinery from a certain unit has been in operation for 350 hours and is in a nearly new condition. People who are not familiar with China might wonder why a machine that has been in use for ten years has only operated for over 300 hours. These machines are the standard equipment of this unit. Whether you can use them or not, many of these machines were allocated to this unit but were never used due to lack of opportunities. They were always stored in the warehouse until the expiration of their service life, when new machines were installed. Regardless of whether the original machines were used or not, they would be forcibly retired.
XCMG QY8D-I 8-Ton Truck Crane Specification
Vehicle weight (total mass) (kg): 10000
Front axle load (kg): 2600
Mid-rear axle load (kg): 7400
Maximum rated total lifting capacity (kg): 8000
Leg span (longitudinal × transverse) (m): 3.825 × 4.000
Maximum lifting moment of the basic boom (kN·m): 235.2
Maximum speed of single rope (main winch) (m/min): 53/96
Lifting arm extension/fall time (s): 35
Full extension/full retraction time of the lifting arm (s): 36
Rotation speed (r/min): 2.8
Main boom length (m): 7.2
Auxiliary boom length (m): 5.5
Extended arm + auxiliary boom (m): 22.1
Maximum driving speed (km/h): 75
Maximum climbing gradient (%): 28
Approach angle (°): 29
Departure angle (°): 11
Minimum turning diameter (m): 16000
Minimum ground clearance (mm): 260
Performance Features
The XCMG QY8D - I crane has a rated lifting capacity of 8 tons, which can easily meet various lifting operation requirements. It can be flexibly adjusted according to specific needs and is suitable for different working sites. It adopts advanced hydraulic systems and intelligent control technology, making the operation simple and convenient, and improving work efficiency and safety. It is equipped with safety devices such as anti-overturning, protective nets, and overload protection to ensure the safety of operators and equipment, and enhance work reliability. It uses advanced power systems and energy-saving technologies to reduce fuel consumption and minimize environmental impact, in line with environmental protection requirements.
Performance features
Daily maintenance of the truck crane
1. Regularly check the tightness of all fastening parts, especially the tightening bolts of the slewing bearing.
2. Regularly inspect and test the operation of the braking system of the lifting mechanism to ensure safe and reliable braking.
3. Every week, perform maintenance on the lower surface of the main boom. Every month, perform maintenance on the main and auxiliary hooks, transmission shafts, the steel wire rope of the entire vehicle, the boom and the pin of the oil cylinder.
4. Replace the gear oil every 12 months. Regularly check the oil level. If the oil level is low, replenish it.
5. Under normal operating conditions, filter or replace the hydraulic oil once every 6 months.
6. Before each operation, check all safety devices of the crane. If any device is damaged or ineffective, repair it to a qualified state before proceeding with the operation.
