High Quality Used XCMG QY80K 80-Ton Truck Mounted Crane For Construction Projects

This is a 2020 XCMG QY80K truck crane. It is an idle machinery of a state-owned unit in China. The vehicle has not been used much. It is equipped with a Mercedes engine and has excellent performance. It offers high cost-effectiveness! The rated lifting capacity of the XCMG QY80K is 80 tons, which can meet the lifting needs of most medium and large-scale projects. For example, in construction, it can be used to lift large building components and mechanical equipment; in bridge construction, it can also complete the lifting operations of heavy bridge parts, providing a strong guarantee for the smooth progress of the project.

XCMG QY80K 80-Ton Truck Mounted Crane Specification

Maximum rated lifting capacity: 80t

Maximum lifting moment: 2675kN·m

Drive/steering: 10×6×6

Maximum driving speed: 75km/h

Turning radius: 11.5m

Gradeability: 40%

Engine model: OM457LA.Ⅲ/9

Output power: 315KW/1900rpm (for driving)

Maximum torque: 2100Nm/1100r/min

Fuel tank capacity: approximately 250L

Performance Features

The XCMG QY80K truck crane is equipped with a 5-axle chassis, with a maximum driving speed of up to 75 km/h. Its drive/steering configuration is 10×6×6. This design enables the crane to adapt to various road conditions, allowing for relatively effortless steering operations even in narrow construction sites or complex road environments, thereby enhancing the equipment's passability and maneuverability. The XCMG QY80K has a 40% climbing slope, which enables the crane to smoothly reach the work site in mountainous areas or construction areas with highly undulating terrain. It features a unique U-shaped cross-section boom, which not only makes the boom lightweight but also ensures it has high strength and load-bearing capacity. The chassis adopts a 5-axle chassis independently designed and manufactured with a full-width cab, the frame is a fully covered walkway plate, uses a torsion-resistant box-type structure, and is made of high-strength steel.

Daily Maintenance of Truck Cranes

1. Regularly check the tightness of all fastening parts, especially the tightening bolts of the slewing bearing.

2. Regularly inspect and test the operation of the braking system of the lifting mechanism to ensure safe and reliable braking.

3. Every week, perform maintenance on the lower surface of the main boom. Every month, perform maintenance on the main and auxiliary hooks, transmission shafts, the steel wire rope of the entire vehicle, the boom and the pin of the oil cylinder.

4. Replace the gear oil every 12 months. Regularly check the oil level. If the oil level is low, replenish it.

5. Under normal operation conditions, filter or replace the hydraulic oil once every 6 months.

6. Before each operation, check all safety devices of the crane. If any device is damaged or ineffective, repair it to a qualified state before proceeding with the operation.
