2019 Second Hand Xugong Qy25K5-1 Handling Heavy Materials For Senegal

2019 Second Hand Xugong Qy25K5-1 Handling Heavy Materials For Senegal

Product Attributes :

XCMG Official Second Hand Boom All Terrain Crane Truck 25 Ton 50 Ton 70 Ton 80 Ton 100 Ton 200 Ton 300 Ton Used Mobile Truck Crane for Sale in Good Condition

1. Specialized boom of octagonal cross section has features of light deadweight, better strength and strong lifting capacity.

2. Advanced built-in boom head, strong structural members and lower sliders with larger area contribute to better stress-bearing capacity and more smooth telescoping movement, and efficiently prevent boom torsion after side loading.

3. Telescoping mechanism is designed reliably. In the telescoping mechanism, both rotation-resistant rope used for thick cable and guide pulley bearing are imported parts and have reliable performance.

4. Excellent welding technology for structural members. Welding robot with advance process used for key welding make reliable quality products.

5. Ferrule-type compression joints are used for pipeline, have features of reliable connection, better tightness and less leakage.

Product Description

About Xugong Qy25k5-1

Model NO.:

25k5-1

Certification:

GS, RoHS, CE, ISO9001

Condition:

Used

Maximum Lifting Height:

>40m

Type:

Straight Arm

Trademark:

XCMG

Transport Package:

Comply with Export Packaging Requirment

In order to ensure that our quality can reassure and satisfy customers

We will conduct a detailed inspection of each crane to ensure that each crane is in good working condition

System inspection items and requirements

Engine inspection requirements: Cold start, successful ignition at the first attempt, smooth idle speed without black smoke, no emulsification on the oil dipstick (normal water resistance); There are no signs of disassembly on the cylinder head screw and the Angle screw. There is no oil leakage or abnormal noise from the turbocharger

2. Appearance inspection requirements: There should be no welding, touchdown painting or deformation marks on the load-bearing parts such as the main beam, outriggers and turntables. The original factory paint surface under the sealing strips of the door and window frames should be intact. There are no scratch marks on the chromium plating layer of the hydraulic cylinder.

3. Safety device test: Height limiter: When the hook is raised to the limit position and triggered, there will be audible and visual alarms in the cab

Three-turn protector: When the steel wire rope is released until only three turns remain, the system automatically locks (anti-disengagement cylinder).

Level: When adjusting the base, observe the position of the bubbles. The level is normal

4. Inspection requirements for the hydraulic system: Observe the fluctuations of the pressure gauge under no-load and full-load conditions respectively, and there should be no abnormal shaking. Take a hydraulic oil sample to check its cleanliness and find no abnormal impurities.

5. Structural system inspection requirements: There should be no cracks or weld repairs at the hinge points of the large and small arms, the box bodies of the outriggers and other force-bearing points. The slewing bearing started and rotated without abnormal noise. After stopping, the radial clearance was measured to be less than 3mm, and the wiring harness was wrapped completely.
